MCD50B, 5096849, 5096 84 9

MCD50B

Article number

5096849

Nominal voltage

U­_N

V

230

SPD to EN 61643-11

Type 1

SPD to IEC 61643-11

Class 1

Lightning protection Zone LPZ

0→2

Impulse discharge current (10/350)

I­_imp

kA

50

Total discharge current (10/350)

I­_{Total 10/350}

kA

50

Nominal discharge current (8/20)

I­_n

kA

50

Arrestor surge current (8/20) [total]

I­_{Total 8/20}

kA

50

Voltage protection level

U_p

kV

1,3

Response time

t_A

ns

<100

Follow current interrupt rating

I­_fi

kA

25

Maximum back-up fuse

A

500

Temperature range

ϑ

°C

-40 - +85

Division unit TE (17.5 mm)

2

Connection cross-section, rigid

mm²

10 - 50

Connection cross-section, multi-wire

mm²

10 - 35

Connection cross-section, flexible

mm²

10 - 25
